738 Dongfang Rd, Pudong Dist, Shanghai.China., Shanghai, China
86-21-50812548
We specialize in refractory metals, for research & development. Molybdenum, Tantalum, Tungsten,Niobium & Zirconium ,
are available in all forms such as ribbon, foil, sheet, wire, rod, strip, bar, plate, capillary tube, sputtering target, tubing & powder.
- PURE TANTALUM
- Tantalum rod (ASTM B365 - 92 R05400)
Diameter:4.0 up to 95mm max. x random length.
- Tantalum wires (ASTM B 365 - 92 R05400 + ASTM F560)
Dia 0.15 up to 3.0mm x coil (at random length)
- Tantalum plate, sheet(ASTM B708 - 98 R05200)
Thick 0.2 up to 1.0 mm x Width up to 500mm max x Length
Thick 1.0 up to 20mm x Width up to 650mm max x Length
- Tantalum foil (ASTM B708 - 98 R05200)
Thick 0.025 up to 0.05mm x Width 100mm max. x Length
- Tantalum Strips (ASTM B708 - 98 R05200)
Thick 0.05 up to 0.1mm x Width up to 130mm max. x Length
- Tantalum seamless tube(ASTM B521 - 98 UNS Grade R05200)
Tantalum capillary tube/pipe (ASTM B521 - 98 UNS Grade R05200)
OD1.0 up to 2.0 mm x WT 0.2 up to 0.35 mm x Length 1 meters max.
Tantalum seamless tube/pipe(ASTM B521 - 98 UNS Grade R05200)
OD2.0 up to 38 mm x WT 0.2 up to 5 mm x Length 6 meters max.
- Tantalum welded tube(ASTM B521 - 98 UNS Grade R05200)
OD10 up to 38 mm x WT 0.2 up to 5 mm x Length 6.20 meters max.
- TANTALUM ALLOY
- Tantalum alloy(Ta10%W, Ta-10W, Ta10W) rod (ASTM B365 - 92 R05255)
Diameter:4.0 up to 95mm max. x random length.
90% tantalum, 10% tungsten;
Tantalum alloy(Ta2.5%W, Ta-2.5W, Ta2.5W) rod (ASTM B365 - 92 R05252)
Diameter:4.0 up to 95mm max. x random length.
97.5% tantalum, 2.5% tungsten;
- Tantalum alloy (Ta10%W, Ta-10W, Ta10W) wires (ASTM B 365 - 92 R05255)
Dia 0.15 up to 3.0mm x coil (at random length)
90% tantalum, 10% tungsten
Tantalum alloy (Ta2.5%W, Ta-2.5W, Ta2.5W) wires (ASTM B 365 - 92 R05252)
Dia 0.15 up to 3.0mm x coil (at random length)
97.5% tantalum, 2.5% tungsten
-Tantalum alloy (Ta10%W, Ta-10W, Ta10W) Sheet (ASTM B708 - 98 R05255)
Thick 0.1 up to 20mm x Width up to 140mm x Length
90% tantalum, 10% tungsten
Tantalum alloy (Ta2.5%W, Ta-2.5W, Ta2.5W) Sheet (ASTM B708 - 98 R05252)
Thick 0.1 up to 20mm x Width up to 140mm x Length
Tantalum 97.5%, Tungsten 2.5%
- Tantalum alloy (Ta2.5W, Ta-2.5W, Ta2.5W) seamless tube(ASTM B521- 98 UNS Grade R05252)
OD2.0 up to 38 mm x WT0.2 up to 5 mm x Length 6 meters max.
- Tantalum alloy (Ta10W, Ta-10W, Ta10W)welded tube(ASTM B521 - 98 UNS Grade
R05255)
OD10 up to 38 mm x WT 0.2 up to 5 mm x Length 6 meters max.
- PURE NIOBIUM
- Niobium rod(ASTM B392 - 95)
Diameter : 95mm max. x random length.
- Niobium wires (ASTM B 392 - 95)
Diameter 0.5 up to 3.0mm x R/L in coil
- Niobium plate(ASTM B393 - 95 R04210)
Thick 0.1 up to 20mm x Width x Length
- Niobium sheet(ASTM B393 - 95 R04210)
Thick 0.076 up to 0.15mm x Width 5 up to 12mm x Length (500gram/spool)
- Niobium foil(ASTM B393)
Thick 0.05 up to 0.10mm x Width 5-13mm x Length
- Niobium seamless tube(ASTM B394 - 99)
Niobium capillary tube/pipe (seamless)
OD1.0 up to 2.0 mm x WT 0.2 up to 0.35 mm x Length 1 meters max.
Niobium tube/pipe (seamless)
OD 2.0 up to 12.7 mm x WT 0.2 up to 5 mm x Length 6 meters max.
- Niobium tubing (welded)
OD 10 up to 38 mm x WT 0.2 up to 5 mm x Length 6 meters max
