Huamei Wire Mesh Co., Ltd. located in the worldwide well-known "Home town of Wire Mesh" --Anping County of Hebei Province, is a modernized enterprise with a history of more than 20 years integrating developing, manufacturing with selling.
The company mainly produces epoxy resin coated wire mesh (also called epoxy coated wire mesh, plastic coated wire mesh and black sprayed wire mesh)：epoxy resin coated iron mesh (also called epoxy coated iron mesh, plastic coated iron mesh and black sprayed iron mesh), epoxy resin coated stainless steel mesh (also called epoxy coated stainless steel mesh, plastic coated stainless steel mesh and black sprayed stainless steel mesh); copper wire mesh: brass wire mesh, red copper wire mesh, phosphor bronze wire mesh; stainless steel mesh: special mesh (Dutch mesh), stainless steel mesh; which are widely used for screening, filtering etc. in machinery, electronics, petroleum, chemical, architecture, pharmaceutical, food, environmental protection and other industries.
We possess sophisticated production equipments and professional technicians. Manufactured exactly based on the State standard GB/T5330-2003 with strict inspection and quality control, our products are of excellent quality. Our "Huayi" brand series of wire mesh, in particular, sells well not only in large-scale industrial and mining enterprises and scientific research institutions in China, but also in America, Japan, South Korea and, Europe etc.. Our products are favorably commented unanimously by customers.
Quality is root for an enterprise to exist, and integrity the ladder to develop.To build a close tie with our consumers, our company has opened offices in Jiangsu's Changzhou and Henan's Xinxiang. We sincerely wish to cooperate with our customers and build splendid future!
Commodity Name: Epoxy resin coated (black or plastic sprayed)iron mesh , which could substitute for galvanized mesh.
Material:Made of superior mild steel wire. Epoxy resin coated (black or plastic sprayed) after plain weaving. A variety of colors for your choice.
Features: The mesh are weaved uniformly and enjoy a solid shape. The coating is tight and smooth,and it won?t hurt your hand. With our unique state of the art technique and superior paint, our product won?t leave chips.
Uses: Filtering of gas or liquid. Also used in seiving particles in which it can substitute for screen
mesh, galvanized wire mesh etc..
Specification: 16?16 18?16 18?18 18?14 26?22m
Wire diameter: BWG30, 31,32, 33, 34, 35, 36, 37, 38, 39.
Roll width:0.914m, lm, 1.2m.
Other sizes can be customized
Commodity Name: Epoxy resin coated (black or plastic sprayed) stainless steel mesh
Category: Epoxy resin coated (black or plastic sprayed) stainless steel mesh , all kinds of epoxy resin
coated (black or plastic sprayed) wire mesh or sheetings etc..
Material: Welded by stainless steel wire. Epoxy resin coated (black or plastic sprayed) differently according to different material.
Features: Uniformly bright colour, good flexibility, corrosion-resistant , non-toxic and environmental friendly. The mesh are weaved uniformly and enjoy a solid shape. The coating is tight and smooth, and it won?t hurt your hand. With our unique state of the art technique and superior paint, our product won?t leave chips.
Uses: Filtering gas or liquid. Also used in sieving for particles in which it can substitute for screen mesh, galvanized wire mesh etc..
Specification: 16?16 18?16 18?18 18?14 26?22m
Wire diameter: BWG30, 31,32, 33, 34, 35, 36, 37, 38, 39.
Roll width:0.914m, lm, 1.2m.
Other sizes can be customized
plastic sprayed stainless mesh specification
mesh wire diamter width length
14?14 BWG31/32 0.6m to 1.5m 100
16?16 BWG31/32 0.6m to 1.5m 100
16?14 BWG31/32 0.6m to 1.5m 100
18?18 BWG31/32 0.6m to 1.5m 100
18?14 BWG31/32 0.6m to 1.5m 100
18?16 BWG31/32 0.6m to 1.5m 100
20?20 BWG32/33 0.6m to 1.5m 100
22?22 BWG32/33 0.6m to 1.5m 100
24?24 BWG33/34 0.6m to 1.5m 100
28?28 BWG33/34 0.6m to 1.5m 100
30?30 BWG33/34 0.6m to 1.5m 100
Product Name:Brass Wire Mesh
Materials: H65、H68 Brass wire.
Uses: Usually used in sieving and flitering in pharmaceutical and food hygiene industy; sifting for
porcelain clay, particles and powder; printing on the porcelain and glassware etc..
Weaving and characteristic :Plain weave ,twill weave, ?人? shape weave etc..
Product Name:Red Copper Wire Mesh
Weaving and characteristic : Plain weave, twill weave, ?人? shape weave etc.. The product is non-magnetic, wear-resistant, anti-static etc..
Product Name: Phosphorus Bronze Wire Mesh
Weaving and characteristic : Plain weave , twill weave, ?人? Shape weave etc.. The product is
non-magnetic, wear-resistant etc..
Uses: Usually used in sieving and flitering in pharmaceutical and food hygiene industy; sifting for porcelain clay, particles and powder; printing on the porcelain and glassware etc..
Product Name: Stainless Steel Mesh
Material：SUS302 、 304 、 316、304L 、 316L stainless steel wire.
Weaving：Plain weave, twill weave, or Duch weave which include plain dutch weave and twill dutch weave.
Performance：Resistant to acid, alkali, heat, wear etc..
Uses： Mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries.
Specification list of stainess steel mesh
mesh wire diameter aperture open area
(mm^2) weight(Pound) /100 Square foot
sw mm Inch mm
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X1 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63
Product Name: Special Mesh (Dutch Mesh)
Huamei Wire Mesh Co.,Ltd. posseses advanced tailoring equipment, so we can offer strips of wire mesh in all kinds of widths, and cut wire mesh into rectangle or square sheets of wire mesh in all kinds of specifications, etc..
Plain dutch weaving
mesh wire diameter absolute filtration rate μm nominal filtration
rate μm
8X85 .014X.0126 318 － 340 250 － 255
12X64 .024X.0165 270 － 285 200 － 205
14X88 .020X.013 225 － 245 150 － 155
20X150 .0098X.007 155 － 165 100 － 105
24X100 .015X.010 115 － 125 80 － 85
30X150 .009X.007 95 － 100 65 － 70
40X200 .007X.0055 65 － 70 55 － 60
50X250 .0055X.0045 55 － 60 40 － 45
80X400 .0049X.0028 43 － 48 35 － 40
Twill dutch weaving
mesh wire diameter absolute filtration rate μm nominal filtration rate μm
20x250 .0098x.0079 110-120 98-105
30x360 .0098x.0060 90-100 80-84
40x560 .0070x.0040 70-75 47-52
120x400 .0040x.0025 50-55 37-43
120x160 .0040x.0025 40-45 28-32
80x700 .0040x.0030 35-40 24-26
200x600 .0024x.0018 28-32 19-21
165x800 .0028x.0020 24-26 14-16
165x1400 .0028x.0016 16-18 9-11
200x1400 .0028x.0016 12-14 5-6
250x1400 .0022x.0016 11-12 3-4
325x2300 .0015x.0010 8-9 2-3
