Nanping Weishi Wood Industry Co.,Ltd. was established in April 2000, We are engaged in producing LVL scaffold planks according to OSHA and ANSI A10.8 requirements , we are the only certified mill in China now , and has been certified to be able to produce OSHA compliant planks , and was granted the certificate on March 6 , 2009 .
Our factory covers total 66,600m2. Our company owns the first-class production line, staff with high education , advanced production technology , sufficient new product research and development ability as well as normative management system . Our aim is offering qualified products and our perfect service to you .
OSHA Compliant LVL scaffold plank
MOE Value (E): 2.0E
Bending(Fb) : 2950 psi
Species : Masson Pine
Glue : WBP/ PF ( Water and Boil Proof Phenolic Formaldehyde Resin Glue)
M.C.: bellow 14%
Thickness of veneers : Core veneers : 2.6mm(-0.1mm,+0.1) ;
Top veneers :1.5mm
Layers : 17-ply
Veneer joints : Overlap and Butt Joint
Thickness : 38.1～44.45mm
Width : 225mm, 235mm,
Length : Within 3900mm
Density : 600kgs/m3
Loading : 36～40m3/40F
Delivery time : 7days
Stencil mark : Mfr. logo , MOE , Proof Test , Shift NO., OSHA , Production Date, Third Party Inspection Agency Logo , Product Serial No., and customer name (optional).
Each plank is proof-loaded to make sure having meet OSHA deflection limits .
And test bond durability by vacuum pressure soak test as per PS1-95 requirements .
All mechanical property data are verified by the agency , and the agency will offer a product serial no. when all test result show qualified .
Finally , the test report will be offered to customers for quality tracking .
We will keep after-sales service by heart and soul .
